Compliance as Code

2021-03-22 1104 words 6 minutes

Contents

Compliance-as-Code

What is compliance as code?

Compliance-as-Code can be summarized as the organizational capability to automate the implementation, verification, remediation, monitoring, and compliance status reporting. This automation comes in the form of code and is integrated into the code repositories used by Devs and Engineers. It becomes “just another piece of code.”

Using code to describe, validate, (possibly) remediate, monitor, and report compliance requirements and status
Measured against regulatory standards and internal governance
Includes (but not limited to):
- Security
- Infrastructure configuration
- Privacy
- Policies: Government, finance, health, etc.
- Licensing (i.e., Open Source)

Why use compliance as code?

Just as with any other *aC, precision and repeatability of code execution eliminate human error.

Precisions and repeatability
Reduced effort on repetition
Integrates compliance into daily practices, mitigating compliance knowledge silos
Enables and simplifies audits through programmatically defined evidence gathering processes

How to use compliance as code?

Code the requirements as a test. Use descriptive approaches as PowerShell Desired State Configuration (DSC) vs just code as they are simpler to understand, read and maintain. Run compliance tests whenever possible, not just at later stages. Run them while in production to detect unexpected changes (drifts) from the described initially.

Implemented as tests (multiple levels)
Promote descriptive approaches vs pure code
Run compliance tests early and frequently (shift left)
Run compliance tests late to detect breaches and drifts (shift right)
Multiple tools available: PowerShell DSC, InsPec, Open Policy Agent

Infrastructure-as-Code

Infrastructure-as-Code (IaC) is a well-known approach by which the infrastructure requirements are described in code and configuration files. In turn, when executed, it generates the infrastructural artifacts necessary to support the solution.

With the advent of virtual infrastructure, IaC found its space and brought all the advantages of code (speed, repeatability, and human error removal). But as with any other artifacts of a solution, we need to validate and enforce quality.

IaC is only an effective tool when you incorporate this into your DevOps process, and you are willing to run tests and validate your code continuously. Otherwise, you run serious risks when it comes to application security and function. With IaC, your applications can be continually updated while running, and everything is still under compliance. This is a significant advantage, but it requires a certain degree of monitoring to react as unknown issues arise.

Challenges

The declarative approach is hard to test
Long test cycles
The complexity of modern architectures
Highly distributed systems

Different Validation Strategies

Static or style checks

Visual inspection
Validates format, naming conventions, structure
Static code analysis, linting, etc.
Can be executed during build pipelines

Unit tests

Validate the correct functionality of each IaC file/directive
Executed after the IaC has been deployed
Executed in the release phase/pipeline

Integration and system tests

Validates the complete flow of the multiple IaC artifacts
Executed after passing unit tests
Typically used in Integration/Quality/Pre-production/Production
Excellent tool for blue/green deployment strategies

Monitoring

Validates alignment with predefined
Identifies drifts
Excellent tool for monitoring platform stability and health

Testing Tools

Pester

Pester is an testing- and mocking framework for PowerShell. Pester is most commonly used for writing unit and integration tests. It is also a base for tools that validate whole environments, cloud deployments, database configurations, etc.

Pester follows a file naming convention *.Tests.ps1, and uses a simple set of functions: Describe, Context, It, Should, and Mock to create a mini-DSL for writing tests.

Tests can be run locally and should be integrated into a build script in a CI pipeline. Pester can produce artifacts such as Code Coverage and Test Result files for reporting results in CI pipeline.

We test our implementation by validating within our tests that the requirements are present in our configuration file. If changes to the ARM template happen, we can still ensure our requirements are met if all tests are passed. The output of these tests is written in a human-readable way and can be interpreted by non-technical people.

In this example, we will query for the Storage Accounts. The object returned will have all configured properties. Otherwise, we can get the deployed resource by using:

Get-AzResource -ResourceType 'Microsoft.Storage/storageAccounts’

To ensure the specification is met, we need to add assertions based on the specification. These assertions should validate that the properties are set correctly on the deployed Azure Resource.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21


# adls.acceptance.spec.ps1

$adls = Get-AzStorageAccount -Name $resource.Name -ResourceGroupName $resource.ResourceGroupName

Describe "$Name Data Lake Storage Account Generation 2" {
    # Mandatory requirement of ADLS Gen 2 are:
    # - Resource Type is Microsoft.Storage/storageAccounts,
    #   as we know we are looking for this it is obsolete to check
    # - Kind is StorageV2
    # - Hierarchical namespace is enabled

    it "should be of kind StorageV2" {
        $adls.Kind | Should -Be "StorageV2"
    }

    it "should have Hierarchical Namespace Enabled" {
        $adls.EnableHierarchicalNamespace | Should -Be $true
    }

    ...
}

Inspec

Inspec is a command line, an open-source tool provided by Chef with an audit and automated testing framework for integration, compliance, and security. It does not require learning a new language, just knowing how to write the desired state of infrastructure resources. With Inspec, you can test the compliance of remotes machines, data, and cloud infrastructures like Azure and others.

Test the desired state Verify your applications and infrastructure’s current desired state according to the code you write.
Human-readable code Reduce friction by writing tests that are easy to understand by anyone.
Extensible Create custom resources with ease and share them easily with others

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14


describe file('/etc/myapp.conf') do
  it { should exist }

its('mode') { should cmp 0644 }
end

describe apache_conf do

its('Listen') { should cmp 8080 }
end

describe port(8080) do
  it { should be_listening }
end

Azure Resource Manager Template Toolkit

The Azure Resource Manager template (ARM template) test toolkit checks whether your template uses recommended practices. When your template isn’t compliant with recommended practices, it returns a list of warnings with the suggested changes. By using the test toolkit, you can learn how to avoid common problems in template development.

The test toolkit provides a set of default tests. These tests are recommendations but not requirements. You can decide which tests are relevant to your goals and customize which tests are run.

The toolkit is a set of PowerShell scripts that can be run from a command in PowerShell or CLI.
